Product Display
Full-automatic Spiral Wind Pipe Machine (SRTF-3000A)

Type SRTF-3000A
Tube Diameter 300mm-1200mm
Panel Thickness 2.0-3.0mm(Galvanized Plate)
1.5-2.0mm(Stainless Steel)
Tube Length 100mm-10000mm
Processing Speed 1m-25m/min
Uncoiler Vertical:Inside-Roll 460mm-520mm
Outside-Roll 1400mm
Maximum Load : 2000KG
Seaming Types Outside Seaming
Mould Steel Mould
Motor Power 45KW/380V
Cutting Power Plasma Cutting
Strip Width 198mm-200mm
Electronic Control System Computer PLC Control
Pneumatic Power 0.5-0.7Mpa
Mains Voltage 380V/50Hz
Dimension 5000mm*2000mm*1800mm
Weight 4000KG
