Product Display
Full-automatic Spiral Wind Pipe Machine (SRTF-2000A)



Type SRTF-2000A
Tube Diameter 100mm-2000mm
Panel Thickness 0.5-2.0mm(Galvanized Plate)
0.5-1.2mm(Stainless Steel)
Tube Length 100mm-10000mm
Processing Speed 1-36m/min
Uncoiler Vertical:Inside-Roll 450-500mm
Outside-Roll 1500mm
Maximum Load:1500KG
Seaming Types Outside Seaming; Inside Seaming according to Customer Demand
Mould Steel Strip; fixed Mould; Three-point Adjustion
Motor Power 15KW/380V
Cutting Power 5.5kw/ Plasma Cutting
Cutting Ways Sawing, Rolling-shear, Plasma Cutting
Strip Width 137mm-140mm
Electronic Control System Computer PLC Control
Pneumatic Power 0.5-0.7Mpa
Mains Voltage 380V/50Hz
Dimension 3500mm*2200mm*2850mm
Weight 2850KG
